Week 2 Interactive Session: Spatial-Temporal Attention Mechanisms

Building attention mechanisms from scratch for geospatial data

Course Roadmap Mapping

This week’s work in the broader GFM plan.

Week Stage Focus You will build (geogfm) Library tools Outcome
2 Stage 1: Build GFM Architecture Attention & Blocks modules/embeddings/{patch_embedding.py, positional_encoding.py}; modules/attention/multihead_attention.py; modules/blocks/{mlp.py, transformer_block.py} torch.nn (compare with torch.nn.MultiheadAttention) Blocks run forward with stable shapes; unit tests green

Weekly goals

  • Implement patch/positional embeddings and MHA from scratch
  • Assemble a PreNorm transformer block (MHA + MLP)
  • Validate tensor shapes and simple layer tests

Session Outline (and Tangled Code)

  • Concepts β†’ Components mapping
    • Patch tokenization β†’ modules/embeddings/patch_embedding.py
    • Positional encoding β†’ modules/embeddings/positional_encoding.py
    • Scaled dot-product multihead self-attention β†’ modules/attention/multihead_attention.py
    • Feedforward/MLP and Transformer block (PreNorm) β†’ modules/blocks/{mlp.py, transformer_block.py}
  • What you will implement
    1. Patch embedding (Conv2d patchify + linear projection)
    2. Sinusoidal positional encodings (1D for tokens; optional 2D helper)
    3. Multihead self-attention from scratch
    4. MLP block and a PreNorm Transformer block

Package inits

# Package init for `geogfm.modules` (Week 2)
# geogfm.modules
# Package init for `geogfm.modules.attention` (Week 2)
# geogfm.modules.attention
# Package init for `geogfm.modules.embeddings` (Week 2)
# geogfm.modules.embeddings
# Package init for `geogfm.modules.blocks` (Week 2)
# geogfm.modules.blocks
# Package init for `geogfm.modules.heads` (Week 2)
# geogfm.modules.heads
# Package init for `geogfm.modules.losses` (Week 2)
# geogfm.modules.losses

1) Patch Embedding β†’ geogfm/modules/embeddings/patch_embedding.py

# Patch embedding layer (Week 2)
from __future__ import annotations
from dataclasses import dataclass
from typing import Tuple
import torch
import torch.nn as nn

@dataclass
class PatchEmbedConfig:
    in_channels: int = 3
    embed_dim: int = 256
    patch_size: int = 16

class PatchEmbedding(nn.Module):
    """Conv2d-based patchifier producing token embeddings.
    Input:  (B, C, H, W)
    Output: (B, N, D) where N = (H/ps)*(W/ps), D = embed_dim
    """
    def __init__(self, cfg: PatchEmbedConfig):
        super().__init__()
        self.cfg = cfg
        self.proj = nn.Conv2d(cfg.in_channels, cfg.embed_dim,
                              kernel_size=cfg.patch_size, stride=cfg.patch_size)

    def forward(self, x: torch.Tensor) -> torch.Tensor:
        # (B, D, H/ps, W/ps) -> (B, D, N) -> (B, N, D)
        x = self.proj(x)
        b, d, gh, gw = x.shape
        x = x.flatten(2).transpose(1, 2)
        return x

2) Positional Encoding (Sinusoidal) β†’ geogfm/modules/embeddings/positional_encoding.py

# Sinusoidal positional encodings (Week 2)
from __future__ import annotations
import math
import torch

def sinusoidal_positional_encoding(seq_len: int, dim: int, device: torch.device | None = None) -> torch.Tensor:
    """Return (seq_len, dim) sinusoidal positional encodings."""
    device = device or torch.device("cpu")
    pe = torch.zeros(seq_len, dim, device=device)
    position = torch.arange(0, seq_len, dtype=torch.float32, device=device).unsqueeze(1)
    div_term = torch.exp(torch.arange(0, dim, 2, device=device).float() * (-math.log(10000.0) / dim))
    pe[:, 0::2] = torch.sin(position * div_term)
    pe[:, 1::2] = torch.cos(position * div_term)
    return pe

def sinusoidal_positional_encoding_2d(height: int, width: int, dim: int, device: torch.device | None = None) -> torch.Tensor:
    """Return (height*width, dim) 2D positional encodings by concatenating two 1D encodings.
    dim must be even.
    """
    assert dim % 2 == 0, "dim must be even for 2D positional encoding"
    device = device or torch.device("cpu")
    pe_h = sinusoidal_positional_encoding(height, dim // 2, device)  # (H, D/2)
    pe_w = sinusoidal_positional_encoding(width, dim // 2, device)   # (W, D/2)
    pe_h = pe_h.unsqueeze(1).expand(height, width, dim // 2)
    pe_w = pe_w.unsqueeze(0).expand(height, width, dim // 2)
    pe = torch.cat([pe_h, pe_w], dim=-1).reshape(height * width, dim)
    return pe

3) Multihead Self-Attention β†’ geogfm/modules/attention/multihead_attention.py

# Multihead self-attention from scratch (Week 2)
from __future__ import annotations
from typing import Optional
import math
import torch
import torch.nn as nn

class MultiheadSelfAttention(nn.Module):
    def __init__(self, embed_dim: int, num_heads: int, attn_dropout: float = 0.0, proj_dropout: float = 0.0):
        super().__init__()
        assert embed_dim % num_heads == 0, "embed_dim must be divisible by num_heads"
        self.embed_dim = embed_dim
        self.num_heads = num_heads
        self.head_dim = embed_dim // num_heads

        self.qkv = nn.Linear(embed_dim, embed_dim * 3)
        self.attn_drop = nn.Dropout(attn_dropout)
        self.proj = nn.Linear(embed_dim, embed_dim)
        self.proj_drop = nn.Dropout(proj_dropout)

    def forward(self, x: torch.Tensor, attn_mask: Optional[torch.Tensor] = None) -> torch.Tensor:
        bsz, num_tokens, dim = x.shape
        qkv = self.qkv(x).reshape(bsz, num_tokens, 3, self.num_heads, self.head_dim).permute(2, 0, 3, 1, 4)
        q, k, v = qkv[0], qkv[1], qkv[2]  # (B, H, N, Hd)

        scale = 1.0 / math.sqrt(self.head_dim)
        attn_scores = (q @ k.transpose(-2, -1)) * scale  # (B, H, N, N)
        if attn_mask is not None:
            attn_scores = attn_scores.masked_fill(attn_mask == 0, float("-inf"))
        attn = attn_scores.softmax(dim=-1)
        attn = self.attn_drop(attn)

        out = attn @ v  # (B, H, N, Hd)
        out = out.transpose(1, 2).reshape(bsz, num_tokens, dim)  # (B, N, D)
        out = self.proj(out)
        out = self.proj_drop(out)
        return out

4) MLP and Transformer Block (PreNorm) β†’ geogfm/modules/blocks/

# MLP feedforward block (Week 2)
from __future__ import annotations
import torch
import torch.nn as nn

class MLP(nn.Module):
    def __init__(self, embed_dim: int, mlp_ratio: float = 4.0, dropout: float = 0.0):
        super().__init__()
        hidden_dim = int(embed_dim * mlp_ratio)
        self.fc1 = nn.Linear(embed_dim, hidden_dim)
        self.act = nn.GELU()
        self.fc2 = nn.Linear(hidden_dim, embed_dim)
        self.drop = nn.Dropout(dropout)

    def forward(self, x: torch.Tensor) -> torch.Tensor:
        x = self.fc1(x)
        x = self.act(x)
        x = self.drop(x)
        x = self.fc2(x)
        x = self.drop(x)
        return x
# PreNorm Transformer block (Week 2)
from __future__ import annotations
import torch
import torch.nn as nn
from geogfm.modules.attention.multihead_attention import MultiheadSelfAttention
from geogfm.modules.blocks.mlp import MLP

class TransformerBlock(nn.Module):
    """PreNorm Transformer block: LN β†’ MHA β†’ Residual β†’ LN β†’ MLP β†’ Residual."""
    def __init__(self, embed_dim: int, num_heads: int, mlp_ratio: float = 4.0, dropout: float = 0.0):
        super().__init__()
        self.norm1 = nn.LayerNorm(embed_dim)
        self.attn = MultiheadSelfAttention(embed_dim, num_heads, proj_dropout=dropout)
        self.norm2 = nn.LayerNorm(embed_dim)
        self.mlp = MLP(embed_dim, mlp_ratio=mlp_ratio, dropout=dropout)

    def forward(self, x: torch.Tensor) -> torch.Tensor:
        x = x + self.attn(self.norm1(x))
        x = x + self.mlp(self.norm2(x))
        return x

Quick Shape Checks (non-tangled)

import torch
from geogfm.modules.embeddings.patch_embedding import PatchEmbedding, PatchEmbedConfig
from geogfm.modules.embeddings.positional_encoding import sinusoidal_positional_encoding
from geogfm.modules.blocks.transformer_block import TransformerBlock

# Dummy image
x = torch.randn(2, 3, 64, 64)
pe = PatchEmbedding(PatchEmbedConfig(in_channels=3, embed_dim=128, patch_size=16))
tokens = pe(x)  # (2, 16, 128)
pos = sinusoidal_positional_encoding(tokens.shape[1], 128, tokens.device)
tokens = tokens + pos.unsqueeze(0)

block = TransformerBlock(embed_dim=128, num_heads=4)
out = block(tokens)
print("tokens ->", tokens.shape, "block out ->", out.shape)
tokens -> torch.Size([2, 16, 128]) block out -> torch.Size([2, 16, 128])
