Week 3 Interactive Session: Complete GFM Architecture

Assembling Vision Transformer architecture for geospatial data

Course Roadmap Mapping

This week’s work in the broader GFM plan.

Week Stage Focus You will build (geogfm) Library tools Outcome
3 Stage 1: Build GFM Architecture Complete Architecture models/gfm_vit.py; modules/heads/reconstruction_head.py torch.nn (timm as reference) Encoder assembled; end-to-end forward on dummy input

Weekly goals

  • Wire blocks into a GeoViT-style encoder
  • Add a simple reconstruction head
  • Run end-to-end forward pass on dummy input

Session Outline (and Tangled Code)

  • Concepts β†’ Components mapping
    • Token pipeline β†’ PatchEmbedding + positional encoding + stack of TransformerBlocks
    • Encoder backbone β†’ models/gfm_vit.py
    • Decoder/readout for MAE β†’ modules/heads/reconstruction_head.py

Package inits

# geogfm.models
# Package init for model modules

1) GeoViT Backbone β†’ geogfm/models/gfm_vit.py

from __future__ import annotations
from dataclasses import dataclass
from typing import List
import torch
import torch.nn as nn
from geogfm.modules.embeddings.patch_embedding import PatchEmbedding, PatchEmbedConfig
from geogfm.modules.embeddings.positional_encoding import sinusoidal_positional_encoding
from geogfm.modules.blocks.transformer_block import TransformerBlock

@dataclass
class ViTBackboneConfig:
    in_channels: int = 3
    image_size: int = 224
    patch_size: int = 16
    embed_dim: int = 256
    depth: int = 8
    num_heads: int = 8
    mlp_ratio: float = 4.0

class GeoViTBackbone(nn.Module):
    def __init__(self, cfg: ViTBackboneConfig):
        super().__init__()
        self.cfg = cfg
        # Tokenization: Conv2d-based patchify + linear projection
        self.patch_embed = PatchEmbedding(PatchEmbedConfig(cfg.in_channels, cfg.embed_dim, cfg.patch_size))
        num_patches = (cfg.image_size // cfg.patch_size) ** 2
        # Fixed positional encodings for stability and speed in the session
        self.pos_embed = nn.Parameter(sinusoidal_positional_encoding(num_patches, cfg.embed_dim), requires_grad=False)
        # Encoder: stack of PreNorm Transformer blocks
        self.blocks = nn.ModuleList([
            TransformerBlock(cfg.embed_dim, cfg.num_heads, mlp_ratio=cfg.mlp_ratio) for _ in range(cfg.depth)
        ])
        self.norm = nn.LayerNorm(cfg.embed_dim)

    def forward(self, x: torch.Tensor) -> torch.Tensor:
        """Return latent token sequence of shape (batch, num_tokens, embed_dim)."""
        tokens = self.patch_embed(x)  # (B, N, D)
        tokens = tokens + self.pos_embed.unsqueeze(0)
        for blk in self.blocks:
            tokens = blk(tokens)
        tokens = self.norm(tokens)
        return tokens  # (B, N, D)

2) Reconstruction Head β†’ geogfm/modules/heads/reconstruction_head.py

from __future__ import annotations
import torch
import torch.nn as nn

class ReconstructionHead(nn.Module):
    """Token-wise MLP to reconstruct patch pixels from latent tokens."""
    def __init__(self, embed_dim: int, out_channels: int, patch_size: int):
        super().__init__()
        self.out_channels = out_channels
        self.patch_size = patch_size
        # Two-layer MLP mapping from token dim D -> (C * P * P)
        self.linear = nn.Sequential(
            nn.Linear(embed_dim, embed_dim),
            nn.GELU(),
            nn.Linear(embed_dim, out_channels * patch_size * patch_size),
        )

    def forward(self, tokens: torch.Tensor) -> torch.Tensor:
        # Transform tokens: (B, N, D) -> (B, N, C*P*P) -> (B, N, C, P, P)
        b, n, d = tokens.shape
        x = self.linear(tokens)
        x = x.view(b, n, self.out_channels, self.patch_size, self.patch_size)
        return x

Quick Forward Check (non-tangled)

import torch

# Use locally defined classes in this session (avoid importing from geogfm here)
x = torch.randn(2, 3, 64, 64)
vit = GeoViTBackbone(ViTBackboneConfig(in_channels=3, image_size=64, patch_size=16, embed_dim=128, depth=2, num_heads=4))
latent = vit(x)
head = ReconstructionHead(embed_dim=128, out_channels=3, patch_size=16)
recon = head(latent)
print("latent:", latent.shape, "recon:", recon.shape)
latent: torch.Size([2, 16, 128]) recon: torch.Size([2, 16, 3, 16, 16])
